Γραμμή επεξεργασίας ντοματών
>
|
|
| Τόπος καταγωγής | Σαγκάη |
| Μάρκα | Gofun |
| Πιστοποίηση | ISO, CE certification |
| Αριθμό μοντέλου | GFM-TPL |
Tomato Sauce Production Line | Tomato Processing Plant for Ketchup and Pizza Sauce
Do you want to produce finished tomato products that go directly to supermarket shelves or restaurant kitchens? This tomato sauce production line takes fresh tomatoes and turns them into retail ready ketchup, pizza sauce, pasta sauce, and tomato juice. Unlike lines that stop at paste, this tomato processing plant includes cooking, seasoning, and packaging equipment.
From Fresh Tomato to Finished Sauce in One Line
The complete system starts with tomato receiving and sorting. Fresh fruit moves through the washer and crusher to the preheater and refiner. At this stage, you have tomato paste or puree. But this tomato processing plant goes further.
The paste moves to stainless steel cooking kettles where you add sugar, salt, vinegar, spices, and other ingredients according to your recipe. The kettles are jacketed for steam or electric heating. Agitators prevent burning and ensure even mixing. Cooking temperature and time are controlled by PLC.
After cooking, the finished sauce passes through a homogenizer for smooth texture. A deaerator removes air bubbles that could cause spoilage or poor sealing. Then the sauce is ready for packaging.
Multiple Packaging Options
This tomato sauce production line connects to various filling machines based on your target market.
For glass bottles, the line includes a rotary bottle filler with capper and labeler. For plastic squeeze bottles for ketchup, the line includes a piston filler with foil induction sealer. For stand up pouches with fitment for easy dispensing, the line includes a pre made pouch filler. For industrial bulk packs for restaurants, the line includes bag in box filling systems.
Products You Can Make
Tomato ketchup in glass or squeeze bottles. Pizza sauce in pouches or plastic tubs. Pasta sauce with herbs in glass jars with twist off lids. Tomato juice in cartons or PET bottles. Barbecue sauce base starting from tomato paste.
Technical Specifications
Fresh tomato input ranges from 500 kilograms to 10 tons per day. Cooking kettle capacity ranges from 200 to 2000 liters per batch. Heating options include steam, electric, or thermal oil. Homogenizer pressure reaches 150 to 250 bar for smooth sauce texture. Packaging speed depends on chosen filler ranging from 20 to 80 containers per minute.
Recipe Customization Support
Not sure how to formulate your sauce? This tomato processing plant comes with recipe support. Standard recipes available include American style ketchup, Italian pizza sauce, Mediterranean pasta sauce, and spicy tomato chutney. Each recipe includes exact ingredient ratios, cooking temperature, cooking time, and final pH targets. Custom recipes can be developed based on your market requirements.
Who This Tomato Sauce Production Line Serves
Small and medium sauce manufacturers launching branded products. Restaurant chains producing their own signature sauce. Tomato growers diversifying into value added products. Food startups entering the shelf stable sauce category.
Ready to Launch Your Tomato Sauce Brand
Contact us with your target daily output, preferred packaging type, and desired sauce style. We will send you a complete tomato sauce production line proposal including machine list, recipe sheet, and customized quote. Free formula sheet and plant layout available.
| Product Name | One-stop solution for tomato processing line |
|---|---|
| Fresh Fruit Input Capacity | 500kg per hour ~ 25 tons per hour |
| Raw Material | Fresh tomato, tomato paste |
| End Product | Tomato paste, tomato sauce or ketchup, tomato juice, etc |
| Final Product Brix | 28%~30%, 36%~38% |
| Main Machine Material | Food grade SUS304 or SUS316 |
| Warranty | 12 months after commissioning |
